Kidney Flange
Kidney Flange
- Features: Integral forged body.
- Working Temperature: PTFE (-65°F to 450°F) & Graphite (-65°F to 649°F)
- Standard Materials: ASME A182 F316.
- Testing: All kidney flanges are 100% factory tested.
Kidney Flange
| RADILOK Part Number | Type | T (End Connection) | L (mm) |
|---|---|---|---|
| KD-8N-F | Concentric | 1/2" NPT-F | 28.0 |
| KD-8T | Concentric | 1/2" RADILOK Tube Fitting | 49.8 |
| KD-12MT | Concentric | 12mm RADILOK Tube Fitting | 50.9 |
| KD-8SW | Concentric | 1/2" Socket Weld | 80.0 |
| KD-E-8N-F | Eccentric | 1/2" NPT-F | 28.0 |
- • Flange Mounting Bolts - High Tensile Carbon Steel.
- • Flange Gasket - PTFE (To order Graphite flange seal material, add suffix 'G' after part number).
- • Eccentric flange needs to be ordered in whole set.
- • A whole eccentric flange set contains 2 eccentric flanges, 2 PTFE flange seal rings & 4 high tensile bolts.
