What is Slip On Raised Face Flanges?
Stainless Steel Slip On Raised Face Flanges have a raised face because the gasket surfaces are
raised above the bolting circle face. These flanges are manufactured with an inside diameter that
is slightly larger than the pipe's outside diameter. A key feature of the Rf slip-on flange is its
differing pressure and temperature ratings for various materials. Duplex Steel Slip On Raised Face
Flanges facilitate a connection of pipes where the connecting pieces have flanges that are bolted
together.
Super Duplex Steel Slip On Raised Face Flanges permit the use of an extensive range of gasket
designs, including flat ring types and metallic mixtures like double jacketed and spiral wound
types. Additionally, these Monel Slip On Raised Face Flanges are designed with standardized
dimensions to allow for easy functionality and interchangeability.
A SORF flange is specifically designed to slip over a pipe and is welded on the outside. Commonly
used across various industries, these flanges are known for their strength and durability. They
are available in different types, such as ring style, flat face, and spiral double jacketed. A
significant benefit of using SORF flanges is the ability to use a wide variety of gaskets.
ASTM A182 Stainless Steel Slip on Raised Face Flange, Raised Face Slip On Flange, Duplex Steel Slip on Raised Face Flanges, Copper Nickel SORF Flanges, Super Duplex Steel Slip on Raised Face Flanges, Manufacturers and Suppliers of Slip on Raised Face Flanges in Various Material Grades.
These flanges are generally made from stainless steel. Consequently, many slip-on raised face
flanges are fabricated from duplex and super duplex steel alloys for enhanced performance.
Raised face flanges are the most popular type of slip-on flange. This design features a lip or face
that is about 1/16 inch tall. The face is recessed to a level lower than the flange's base, which
allows a gasket to be used to create a secure seal. In contrast, a flat face flange does not have
this raised lip.
Another common type is the SO flange, which has a simple design and is welded to a pipe. It is
frequently used in low-pressure, medium-temperature piping systems. The ability to weld the SO
flange directly to a pipe offers many conveniences, such as connecting to equipment or machinery
with a fillet weld.
A raised face slip-on flange can be manufactured with a standard height of 1/16 inch for
applications under 400#. For larger pressure ratings, the height of the raised face is increased,
which enhances the joint's ability to contain pressure. Most flanges include a ring positioned above
the bolting circle to prevent leakage.
Hastelloy Slip on Raised Face Flanges Exporters, High Nickel Alloy SORF Flanges, Brass Slip on Raised Face Flange Dealers, Inconel Slip on Raised Face Flanges, Incoloy SORF Flanges, Alloy 20 Slip on Raised Face Flanges, Monel Alloy Slip on Raised Face Flanges, SS Slip on Raised Face (SORF) Flanges Stockists and Stockholders.
Frequently Ask Question
Slip on Raised Face (SORF) Flange Specifications
Slip on Raised Face (SORF) Specification
| Standard | ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings |
| Size | 1/2" (15 NB) to 48" (1200NB) |
| Class | 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc. |
| BS | BS4504, BS1560, BS10 |
| DIN | DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636,DIN2637, DIN2638, DIN2673 |
| Pressure Ratings | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 |
| Flange Face Type | Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
Raised Face Slip On Flange Material and Grades
| Stainless Steel Slip on Raised Face Flanges | ASTM A 182, A 240 F 304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H,904L |
| Duplex and Super Duplex Steel Slip on Raised Face Flanges | ASTM / ASME A/SA 182 F 44, F 45, F51, F 53, F 55, F 60, F 61 |
| Carbon Steel Slip on Raised Face Flanges | ASTM / ASME A/SA 105 ASTM / ASME A 350, ASTM A 181 LF 2 / A516 Gr.70 A36, A694 F42, F46, F52, F60, F65, F706 |
| Alloy Steel Slip on Raised Face Flanges | ASTM / ASME A/SA 182 & A 387 F1, F5, F9, F11, F12, F22, F91 |
| Nickel Alloy Slip on Raised Face Flanges | ASTM SB564, SB160, SB472, SB162 Nickel 200 (UNS No. N02200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020) |
| Copper Alloy Slip on Raised Face Flanges | ASTM SB 61, SB62, SB151, SB152 UNS No. C 70600 (Cu-Ni 90/10), C 71500 (Cu-Ni 70/30), UNS No. C 10100, 10200, 10300, 10800, 12000, 12200 |
| Low Temperature Carbon Steel Slip on Raised Face Flanges | ASTM A350, LF2, LF3 |
