Heavy Series
Heavy Series
Tube Clamps
- Material: Polypropylene (PP)
- Clamp Color: Green
- Operating Temperature: -30°C to +90°C
- Material of Top Plate: CS Galvanised
- Material of bottom Plate: CS
- Fixing Screw: Hex Head Bolt CS Zinc Plated
Application:
- Tube Clamps are one of the best solution to assure the reliable tubing line support system for clamping, fastening and installing.
- Hydraulic pipe clamps ensures the clamps can greatly reduce the impact, vibration and, reduce system noise, and they are used in various hydraulic systems.
- The most typical pipe clamps are designed and made according to DIN 3015.
Pipe Gauge 90° Syphon
| RADILOK Part Number | Clamp Group | Pipe OD | Pipe Size NB | L (mm) | L1 (mm) | H (mm) | H1 (mm) | B (mm) | Hex Bolt | |
|---|---|---|---|---|---|---|---|---|---|---|
| Metric Size | Fractional Size | |||||||||
| FPCH-6M | 1 | 6 mm | 1/4" | - | 55.0 | 70.0 | 23.0 | 48.0 | 32.0 | M10 X 45 |
| FPCH-8M | 8 mm | 5/16" | - | 55.0 | 70.0 | 23.0 | 48.0 | 32.0 | M10 X 45 | |
| FPCH-10M | 10 mm | 3/8" | - | 55.0 | 70.0 | 23.0 | 48.0 | 32.0 | M10 X 45 | |
| FPCH-12M | 12 mm | 1/2" | 1/4" | 55.0 | 70.0 | 23.0 | 48.0 | 32.0 | M10 X 45 | |
| FPCH-14M | 14 mm | - | - | 55.0 | 70.0 | 23.0 | 48.0 | 32.0 | M10 X 45 | |
| FPCH-15M | 15 mm | - | - | 55.0 | 70.0 | 23.0 | 48.0 | 32.0 | M10 X 45 | |
| FPCH-16M | 16 mm | - | 3/8" | 55.0 | 70.0 | 23.0 | 48.0 | 32.0 | M10 X 45 | |
| FPCH-18M | 18 mm | - | - | 55.0 | 70.0 | 23.0 | 48.0 | 32.0 | M10 X 45 | |
| FPCH-19M | 2 | 19 mm | 3/4" | - | 70.0 | 85.0 | 30.0 | 60.0 | 32.0 | M10 X 60 |
| FPCH-20M | 20 mm | - | 1/2" | 70.0 | 85.0 | 30.0 | 60.0 | 32.0 | M10 X 60 | |
| FPCH-22M | 22 mm | - | - | 70.0 | 85.0 | 30.0 | 60.0 | 32.0 | M10 X 60 | |
| FPCH-25M | 25 mm | 1" | 3/4" | 70.0 | 85.0 | 30.0 | 60.0 | 32.0 | M10 X 60 | |
| FPCH-26M | 26 mm | - | - | 70.0 | 85.0 | 30.0 | 60.0 | 32.0 | M10 X 60 | |
| FPCH-28M | 28 mm | - | - | 70.0 | 85.0 | 30.0 | 60.0 | 32.0 | M10 X 60 | |
| FPCH-30M | 30 mm | - | - | 85.0 | 100.0 | 39.0 | 78.0 | 32.0 | M10 X 75 | |
| FPCH-33M | 3 | 33 mm | - | 1" | 85.0 | 100.0 | 39.0 | 78.0 | 32.0 | M10 X 75 |
| FPCH-35M | 35 mm | - | - | 85.0 | 100.0 | 39.0 | 78.0 | 32.0 | M10 X 75 | |
| FPCH-38M | 38 mm | 1.1/2" | - | 85.0 | 100.0 | 39.0 | 78.0 | 32.0 | M10 X 100 | |
| FPCH-42M | 42 mm | - | 1.1/4" | 115.0 | 140.0 | 52.0 | 104.0 | 50.0 | M10 X 100 | |
| FPCH-48M | 4 | 48 mm | - | 1.1/2" | 115.0 | 140.0 | 52.0 | 104.0 | 50.0 | M10 X 100 |
| FPCH-50M | 50 mm | 2" | - | 115.0 | 140.0 | 52.0 | 104.0 | 50.0 | M10 X 100 | |
| FPCH-56M | 56 mm | - | - | 115.0 | 140.0 | 52.0 | 104.0 | 50.0 | M10 X 100 | |
| FPCH-60M | 60 mm | - | 2" | 115.0 | 140.0 | 52.0 | 104.0 | 50.0 | M10 X 100 | |
| FPCH-73M | 73 mm | - | - | 150.0 | 180.0 | 70.0 | 140.0 | 60.0 | M10 X 140 | |
| FPCH-78M | 5 | 78 mm | - | 3" | 150.0 | 180.0 | 70.0 | 140.0 | 60.0 | M10 X 140 |
| FPCH-88.9M | 88.9 mm | - | - | 150.0 | 180.0 | 70.0 | 140.0 | 60.0 | M10 X 140 | |
